Unidoor Plus
Unidoor Plus

Unidoor Plus

Shower Door

Unidoor Plus
Unidoor Plus
Unidoor Plus
Unidoor Plus
Unidoor Plus
Unidoor Plus
Unidoor Plus
Unidoor Plus
Unidoor Plus
Shower Door Handle in Chrome finish
Shower Door Handle in Brushed Nickel finish
Shower Door Handle in Oil Rubbed Bronze finish
Unidoor Plus
Unidoor Plus
Unidoor Plus

PRODUCT SPECIFICATION

  • Finished walls are required for accurate shower opening width measurement
  • U-channel provides up to 1/2 in. width (horizontal) or out-of-plumb (vertical) adjustment
  • Frameless glass design
  • Model consists of single hinged door and one stationary inline panel
  • Reversible for a right or left door opening
  • 3/8 in. (10mm) thick ANSI certified tempered glass with fingerprint free frosted privacy band
  • Hardware available in chrome, brushed nickel or oil rubbed bronze finish
  • Solid brass self-closing hinges (with a 5 degree offset)
  • Wall studs or other reinforcement behind finished walls required for hinge installation
  • Shower base is not included

  • Professional installation recommended

    Note: To minimize leakage, install shower head opposite of door opening aimed at tiled walls, fixed shower panel or floor

    Product Warranty:
  • Limited Lifetime Warranty
  • Warranty for any hardware in Oil Rubbed Bronze finish is limited to 1 (one) year

The UNIDOOR PLUS shower door from DreamLine® is perfectly designed to accommodate today‚Äôs trends. It has a classic frameless design with three hardware finish options helping it enhance any bathroom style on any budget. With equal appeal and versatility as the original UNIDOOR, the UNIDOOR PLUS shower door adds an extra splash of class with an anodized aluminum U-channel. The UNIDOOR PLUS shower door combines premium 3/8 in. thick ANSI certified tempered glass with a sleek frameless design for the look of custom glass at an unparalleled value. With clean lines, modern accents, an upscale look and a choice of clear or frosted (band) privacy glass, the UNIDOOR PLUS shower door adds a touch of timeless style to any bathroom space. DreamLine® has the ultimate solution for your shower project.

WIDTH RANGES

Please select range bellow

29" - 37"
+
Configuration SKU A B C - Walk-In

SHDR-242907210

29" - 29 1/2"

72"

22"

SHDR-242957210

29 1/2" - 30"

72"

22"

SHDR-243007210

30" - 30 1/2"

72"

23"

SHDR-243057210

30 1/2" - 31"

72"

23"

SHDR-243107210

31" - 31 1/2"

72"

24"

SHDR-243157210

31 1/2" - 32"

72"

24"

SHDR-243207210

32" - 32 1/2"

72"

25"

SHDR-243257210

32 1/2" - 33"

72"

25"

SHDR-243307210

33" - 33 1/2"

72"

26"

SHDR-243357210

33 1/2" - 34"

72"

26"

SHDR-243407210

34" - 34 1/2"

72"

27"

SHDR-243457210

34 1/2" - 35"

72"

27"

SHDR-243507210

35" - 35 1/2"

72"

28"

SHDR-243557210

35 1/2" - 36"

72"

28"

SHDR-243607210

36" - 36 1/2"

72"

29"

SHDR-243657210

36 1/2" - 37"

72"

29"

Configuration SKU A B C - Walk-In

SHDR-242907210-HFR

29" - 29 1/2"

72"

22"

SHDR-242957210-HFR

29 1/2" - 30"

72"

22"

SHDR-243007210-HFR

30" - 30 1/2"

72"

23"

SHDR-243057210-HFR

30 1/2" - 31"

72"

23"

SHDR-243107210-HFR

31" - 31 1/2"

72"

24"

SHDR-243157210-HFR

31 1/2" - 32

72"

24"

SHDR-243207210-HFR

32" - 32 1/2"

72"

25"

SHDR-243257210-HFR

32 1/2" - 33"

72"

25"

SHDR-243307210-HFR

33" - 33 1/2"

72"

26"

SHDR-243357210-HFR

33 1/2" - 34"

72"

26"

SHDR-243407210-HFR

34" - 34 1/2"

72"

27"

SHDR-243457210-HFR

34 1/2" - 35"

72"

27"

SHDR-243507210-HFR

35" - 35 1/2"

72"

28"

SHDR-243557210-HFR

35 1/2" - 36"

72"

28"

SHDR-243607210-HFR

36" - 36 1/2"

72"

29"

SHDR-243657210-HFR

36 1/2" - 37"

72"

29"

37" - 45"
+
Configuration SKU A B C - Walk-In

SHDR-243707210

37" - 37 1/2"

72"

22"

SHDR-243757210

37 1/2" - 38"

72"

22"

SHDR-243807210

38" - 38 1/2"

72"

23"

SHDR-243857210

38 1/2" - 39"

72"

23"

SHDR-243907210

39" - 39 1/2"

72"

24"

SHDR-243957210

39 1/2" - 40"

72"

24"

SHDR-244007210

40" - 40 1/2"

72"

25"

SHDR-244057210

40 1/2" - 41"

72"

25"

SHDR-244107210

41" - 41 1/2"

72"

26"

SHDR-244157210

41 1/2" - 42"

72"

26"

SHDR-244207210

42" - 42 1/2"

72"

27"

SHDR-244257210

42 1/2" - 43"

72"

27"

SHDR-244307210

43" - 43 1/2"

72"

28"

SHDR-244357210

43 1/2" - 44"

72"

28"

SHDR-244407210

44" - 44 1/2"

72"

29"

SHDR-244457210

44 1/2" - 45"

72"

29"

Configuration SKU A B C - Walk-In

SHDR-243707210-HFR

37" - 37 1/2"

72"

22"

SHDR-243757210-HFR

37 1/2" - 38"

72"

22"

SHDR-243807210-HFR

38" - 38 1/2"

72"

23"

SHDR-243857210-HFR

38 1/2" - 39"

72"

23"

SHDR-243907210-HFR

39" - 39 1/2"

72"

24"

SHDR-243957210-HFR

39 1/2" - 40"

72"

24"

SHDR-244007210-HFR

40" - 40 1/2"

72"

25"

SHDR-244057210-HFR

40 1/2" - 41"

72"

25"

SHDR-244107210-HFR

41" - 41 1/2"

72"

26"

SHDR-244157210-HFR

41 1/2" - 42"

72"

26"

SHDR-244207210-HFR

42" - 42 1/2"

72"

27"

SHDR-244257210-HFR

42 1/2" - 43"

72"

27"

SHDR-244307210-HFR

43" - 43 1/2"

72"

28"

SHDR-244357210-HFR

43 1/2" - 44"

72"

28"

SHDR-244407210-HFR

44" - 44 1/2"

72"

29"

SHDR-244457210-HFR

44 1/2" - 45"

72"

29"

45" - 53"
+
Configuration SKU A B C - Walk-In

SHDR-244507210

45" - 45 1/2"

72"

22"

SHDR-244557210

45 1/2" - 46"

72"

22"

SHDR-244607210

46" - 46 1/2"

72"

23"

SHDR-244657210

46 1/2" - 47"

72"

23"

SHDR-244707210

47" - 47 1/2"

72"

24"

SHDR-244757210

47 1/2" - 48"

72"

24"

SHDR-244807210

48" - 48 1/2"

72"

25"

SHDR-244857210

48 1/2" - 49"

72"

25"

SHDR-244907210

49" - 49 1/2"

72"

26"

SHDR-244957210

49 1/2" - 50"

72"

26"

SHDR-245007210

50" - 50 1/2"

72"

27"

SHDR-245057210

50 1/2" - 51"

72"

27"

SHDR-245107210

51" - 51 1/2"

72"

28"

SHDR-245157210

51 1/2" - 52"

72"

28"

SHDR-245207210

52" - 52 1/2"

72"

29"

SHDR-245257210

52 1/2" - 53"

72"

29"

Configuration SKU A B C - Walk-In

SHDR-244457210-HFR

45" - 45 1/2"

72"

22"

SHDR-244557210-HFR

45 1/2" - 46"

72"

22"

SHDR-244607210-HFR

46" - 46 1/2"

72"

23"

SHDR-244657210-HFR

46 1/2" - 47"

72"

23"

SHDR-244707210-HFR

47" - 47 1/2"

72"

24"

SHDR-244757210-HFR

47 1/2" - 48"

72"

24"

SHDR-244807210-HFR

48" - 48 1/2"

72"

25"

SHDR-244857210-HFR

48 1/2" - 49"

72"

25"

SHDR-244907210-HFR

49" - 49 1/2"

72"

26"

SHDR-244957210-HFR

49 1/2" - 50"

72"

26"

SHDR-245007210-HFR

50" - 50 1/2"

72"

27"

SHDR-245057210-HFR

50 1/2" - 51"

72"

27"

SHDR-245107210-HFR

51" - 51 1/2"

72"

28"

SHDR-245157210-HFR

51 1/2" - 52"

72"

28"

SHDR-245207210-HFR

52" - 52 1/2"

72"

29"

SHDR-245257210-HFR

52 1/2" - 53"

72"

29"

53" - 61"
+
Configuration SKU A B C - Walk-In

SHDR-245307210

53" - 53 1/2"

72"

22"

SHDR-245357210

53 1/2" - 54"

72"

22"

SHDR-245407210

54" - 54 1/2"

72"

23"

SHDR-245457210

54 1/2" - 55"

72"

23"

SHDR-245507210

55" - 55 1/2"

72"

24"

SHDR-245557210

55 1/2" - 56"

72"

24"

SHDR-245607210

56" - 56 1/2"

72"

25"

SHDR-245657210

56 1/2" - 57"

72"

25"

SHDR-245707210

57" - 57 1/2"

72"

26"

SHDR-245757210

57" 1/2 - 58"

72"

26"

SHDR-245807210

58" - 58 1/2"

72"

27"

SHDR-245857210

58 1/2" - 59"

72"

27"

SHDR-245907210

59" - 59 1/2"

72"

28"

SHDR-245957210

59 1/2" - 60"

72"

28"

SHDR-246007210

60" - 60 1/2"

72"

29"

SHDR-246057210

60 1/2" - 61"

72"

29"

Configuration SKU A B C - Walk-In

SHDR-245307210-HFR

53" - 53 1/2"

72"

22"

SHDR-245357210-HFR

53 1/2" - 54"

72"

22"

SHDR-245407210-HFR

54" - 54 1/2"

72"

23"

SHDR-245457210-HFR

54 1/2" - 55"

72"

23"

SHDR-245507210-HFR

55" - 55 1/2"

72"

24"

SHDR-245557210-HFR

55 1/2" - 56"

72"

24"

SHDR-245607210-HFR

56" - 56 1/2"

72"

25"

SHDR-245657210-HFR

56 1/2" - 57"

72"

25"

SHDR-245707210-HFR

57" - 57 1/2"

72"

26"

SHDR-245757210-HFR

57 1/2" - 58"

72"

26"

SHDR-245807210-HFR

58" - 58 1/2"

72"

27"

SHDR-245857210-HFR

58 1/2" - 59"

72"

27"

SHDR-245907210-HFR

59" - 59 1/2"

72"

28"

SHDR-245957210-HFR

59 1/2" - 60"

72"

28"

SHDR-246007210-HFR

60" - 60 1/2"

72"

29"

SHDR-246057210-HFR

60 1/2" - 61"

72"

29"
